DTF UV (30cm)

Related Products

•

  Plotter UV 3040

  1 Epson I3200 printhead

  • SPEED
    0.28 m²/h - 3 m²/h

  • MEDIA
    Glass, plates, various signs, crystal...

  Maintenance

  • Daily Power On and Circulation Even if you're not printing, turn it on every day to circulate the UV ink and prevent it from hardening inside the printhead.
  • Cleaning the Wiper, Cap Station, and Surrounding Area Do this daily. UV ink is thicker and crusts up quickly, clogging the nozzles.
  • Avoid Direct Light on the Ink UV inks are cured by light. Keep the cartridges and the plotter area away from sunlight or external UV lights.
  • Nozzle Check 1–2 Times a Day UV ink tends to dry faster. You detect any cuts before they affect a job.
  • Manual printhead cleaning (only when necessary) Do this with UV cleaning solution and a lint-free cloth. Never use alcohol.
  • Proper ventilation of the work area UV inks emit fumes. A well-ventilated environment improves the life of the equipment and the health of the operator.

  Max width: 420mm

  Speed: 3 m2/h

  Media: Glass, plates, advertising signage, crystal, PVC, acrylic, synthetic leather, etc.

  See more

  Request a quote
•

  DTF UV (60cm)

  3 cabezales Epson I3200

  Maintenance

  • Daily Power On and Circulation Even if you're not printing, turn it on every day to circulate the UV ink and prevent it from hardening inside the printhead.
  • Cleaning the Wiper, Cap Station, and Surrounding Area Do this daily. UV ink is thicker and crusts up quickly, clogging the nozzles.
  • Avoid Direct Light on the Ink UV inks are cured by light. Keep the cartridges and the plotter area away from sunlight or external UV lights.
  • Nozzle Check 1–2 Times a Day UV ink tends to dry faster. You detect any cuts before they affect a job.
  • Manual printhead cleaning (only when necessary) Do this with UV cleaning solution and a lint-free cloth. Never use alcohol.
  • Proper ventilation of the work area UV inks emit fumes. A well-ventilated environment improves the life of the equipment and the health of the operator.
  • Cooling system maintenance Check the water in the chiller or printhead cooling system. If the cooling fails, the printhead can be damaged in minutes.

  Max width: 620mm

  Speed: 10 m2/h

  Media: Film A (with adhesive) + B / Film A (without adhesive) + B

  See more

  Request a quote
•

  DTF 6 Printhead

  6 cabezales Epson I3200

  • High Speed 6-printhead design; maximum achievable speed is 32 m²/h.
  • White-Ink Circulation System Prevents white-ink clogging and ensures more stable printing.
  • Robust Body Japanese steel guide rail; integrated high-strength stand.
  • Built-in Air Purifier Powder agitator with fume-purification function, electronic cleaner, and oil-fume separation.
  • Intelligent Printhead Plate Heating The head heats automatically according to temperature to achieve uniform printing.
  • Smart Touchscreen Easier operation thanks to the touch control panel.

  Compatibility: Standard PhotoPrint and others.

  Maintenance

  • Dust-Free Environment Keep the work environment dust-free to prevent it from affecting printing.
  • Temperature and Humidity The machine should operate at a temperature of **25-30°C** and with a humidity of **40-60%**.
  • Platform Cleaning Keep the entire printer tidy and clean, removing dust from friction areas.
  • Cleaning the Underside of the Printhead Move the carriage to the cleaning position, clean the underside of the printhead with a **non-woven cloth dampened with cleaning fluid or distilled water**, removing dirt from the printhead and surrounding areas.

  Max width: 600mm

  Speed: 36 m2/h

  Media: Pet film 600

  See more

  Request a quote
•

  ORIC 60 CM 2 Cabezales

  2 Epson I3200 printheads

  • Maintenance Dust-Free Environment Keep the work environment dust-free to prevent it from affecting printing.
  • Temperature and Humidity The machine should operate at a temperature of 25–30°C and a humidity of 40–60%.
  • Platform Cleaning Keep the entire printer tidy and clean, removing dust from friction areas.
  • Cleaning the Underside of the Printhead Move the carriage to the cleaning position, clean the underside of the printhead with a non-woven cloth dampened with cleaning fluid or distilled water, removing dirt from the printhead and surrounding areas.

  Max width: 600mm

  Speed: 10 m2/h

  Media: Pet Film 620mm

  See more

  Request a quote
